Range Master ER-8102P-3 - Page 11

AFTER SALES SUPPORT
ITEM #
45090-14
email: rangemaster@1800acs.com
888-892-2075
11
STEP7 INSERT GREASE TRAY
— Slide the grease tray(4) into the slots provided in the base of the BBQ housing
4
STEP 6 CONNECTTHEREGULATORTOTHEBURNER
— Screw the front nut in a clockwise motion into the burner. This brass nut should be 1/4 turn past tight.
 DONOTOVERTIGHTEN.
The regulator assembly will rotate from left to right when the brass nut is tightened, this is normal.
8
IFYOUNEEDHELPORHAVEAWARRANTYORCUSTOMERSERVICEQUERY,
PLEASECALL888-892-2075.
DONOTRETURNTOPLACEOFPURCHASE.
