All Models:
38) Run threaded rod through the angle bracket on each side of the head unit and tighten the cables up.
Use handle OR winch to lift the head unit 152mm – 205mm (6” – 8”) and place a level on the top of blade cover,
adjust cables until head is level. Measure distance from the blade log support on each side to double check that
head unit is level.
39) Install log holder into frame rails, There are multiple frame holes for mounting, choose the one that works best
for your application.
