- 6 -
7. INSTALL THE ROUGH-IN PLATE AND INSTALL THE DEVIATOR
Secure the rough-in plate in the hood with 4 lock nuts. YOU MUST also install the deviator if you choose the vertical
opening. (see picture below)
Note: The deviator will not slide entirely into the hood, you will notice 1/8” will remain.
8. INSTALL THE ADAPTER
Using (2) 1/2’’ screws, secure the adapter to the top or back of the hood. Tape the adapter to the hood using
duct tape to seal it.
