It is dangerous to alter the specifications or attempt to modify this chimney
hood in any way.
TECHNICAL INFORMATION
DIMENSIONS CANOPY: Height 60mm
Width 1198mm
Depth 490mm
CHIMNEY: Height - Upper Chimney 215mm
Lower Chimney 740mm
Width 300mm
Depth 260mm
ELECTRICAL SUPPLY VOLTAGE: ~50Hz 230V
POWER CONSUMPTION: 200W
FAN: 140W
SPOTLAMPS: 3x20W 60W
PERFORMANCE SPEEDS 3
CAPACITY m
3
/h* 550
CAPACIITY m
3
/h** 690
PRESSURE PA 340
INPUT W 200
NOISE LEVEL dBA*** 67
*IEC 61591 method for cooker hoods in evacuation mode - ** IEC 61591 method with free delivery - ***IEC
60704-2-13 method
Note: CE Marking certifies that this appliance complies with the requirements
laid down in EEC directive 89:336 (Electromagnetic compatibility) and
subsequent modifications and Low Voltage directive 72/23/E.
INSTALLATION INSTRUCTIONS
