14
7. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Base of the hob
COUNTRY OF DESTINATION: GB/IE
Dimensions
Height Above worktop: 5mm
Below worktop: 40mm
(60mm including connection box)
Overall width 580mm; see ‘Positioning of the hob’
Overall depth 510mm
Space for fixing See ‘Positioning of the hob’
Minimum space above hotplate 650mm
Connections
Electric
220 – 240V 50Hz
Ratings
Maximum electric load at 230V 50Hz: 5.8kW
