Rangemaster RC77 - Technical Data

15
7. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Base of the hob
COUNTRY OF DESTINATION: GB/IE
Dimensions
Height
Overall: 45mm;
(65mm including connection box)
Above worktop: 5mm;
Below worktop: 40mm
Overall width 770mm; see ‘Positioning of the hob’
Overall depth 510mm
Space for fixing See ‘Positioning of the hob’
Minimum space above hotplate 600mm
Connections
Electric
220 – 240V 50Hz
Ratings
Maximum electric load at 230V 50Hz: 5.8kW
Art No. 315-0007 RC77 hob








DocNo.102-0002 - Technical data - RC77
