Rangemaster RDXD21 - Circuit Diagram

28
8. Circuit diagram
ArtNo.095-0003 - Circuit diagram - 90 induction
121110 987654321
87654321
10 987654321
12345678910
1234567
DISPLAY
1 23456789
123456
12
54321
321
SHABBAT
N PE L
DEF. HEATER
THERMAL FUSE
EVAP FAN
VALVE
PL500
PL501
PL505
PL510
AT SENSOR
FREEZER-1 SENSOR
COOLER SENSOR
COOLER EVAP SENSOR
DEFROST SENSOR
PL509
PL507
DOOR SWITCH 1
DOOR SWITCH 2
DOOR SWITCH 3
DOOR SWITCH 4
20BD10
MAINBOARD
PL513
COOLER FAN
PL508
TRIZBAR RESISTANCE
PL514
KAPI KOLU LEDI
DOOR HANDLE LED
SOGUTUCU LED1-4
REFRIGERATOR LED-4
SOL KAPI ICI LEDI
LEFT INDOOR LED
SAG KAPI ICI LEDI
RIGHT INDOOR LED
COMP.
INVERTER
CARD
N - L - C
COOLER
EVAP HEATER
PL512
PL511
OPTIONAL
