Rangemaster RSXS19BL/C - 3 Using the Control Panel

10
88
88
eco
mode q drink s.saver
°c
-88
°c
-88
°c
sc sf
zone 1 zone 2
min
cooler
Start Ready Vacuum Sealing Done
!
6
4
5
3
2
1
10
11
12
13
7
19
1820 1416 15
98
17
LCD Display
24 25232221
26
Vseal
Fig. 3.1
Using the Control Panel
1. Cooler button
2. Mode button
3. Holiday Mode
4. Economy mode
5. CircFresh
6. q drink timer
7. q drink light
8. Super cooling light
9. Super freezing light
10. Child lock
11. Low voltage warning
12. Service alarm
13. Screensave button
14. Zone 2 (right freezer) button
15. Right freezer compartment temperature indicator
16. Left freezer compartment temperature indicator
17. Zone 1 (left freezer) button
18. q drink mode button
19. Fridge compartment temperature indicator
20. Night sensor
21. Vseal™ Start button
22. Vseal™ Ready indicator
23. Vseal™ Indicator
24. Vseal™ Sealing Indicator
25. Vseal™ Done Indicator
26. Vseal™ Symbol
3. Using the Control Panel
LCD Display
