Your Livewell Aeration System
25
SALTWATER LIVEWELL PLUMBING SYSTEM
MODELS 168, 169, 173, 183, 191, 223, 2000, 2200, 2300, 2400
PUMP
FILTER
VALVE
Aer. Head
w/valve
Directional
Aer. Head
1 1/2” Standpipe
1 1/8” Plug Drain
Operation Instructions:
Your livewell Aeration System
1: Valve (shown in closed position) should be left open
2: Close valve when cleaning filter or servicing pump.
3: The livewell (all except optional leaning post/bait well) aerator head is
adjustable with a valve. The head also is threaded for a hose connection.
Recirculate pump does not have valve.
4: Install drain plug (1-1/8”) or overflow pipe (1-1/2” ) in livewell to hold water.
Pull to drain.
