Your RangerTrail
®
Trailer
On swing hitch trailers, make sure the hitch is in the forward position
and the locking pin is properly installed. Connect your trailer wire harness
and test your vehicle lights to make sure that the trailer’s brake and turn
signals duplicate your vehicles. Remove any trailer wheel chock and
carefully pull away.
To unhitch your trailer from the tow vehicle, place the trailer on a level
and paved surface and chock both trailer wheels to prevent any
movement forward or backward. Unhook the safety chains, wiring
harness and, if so equipped, the brake break-away cable. Then, using the
trailer tongue jack, raise the hitch up and clear the ball. In this position the
trailer tongue should be left somewhat bow high so that any water will run
out through the drain hole in the stern of the boat.
71
Retract jack fully before towing! Replace
coupler and ball if worn… do not attempt
repair or adjustment.
CAUTION
HITCH CLASS RATING MID-SIZE CARS FULL-SIZE CARS FULL-SIZE TRUCKS,
MINI-TRUCKS VANS & SUV’S
& VANS
Class II
WC GTW - Up to 3,500 lbs. Medium Duty Medium Duty Medium Duty
WC TW - up to 350 lbs.
Class III
WC GTW - Up to 5,000 lbs. Heavy Duty Heavy Duty
WC TW - up to 500 lbs.
Class IV
WC GTW - Up to 7,500 lbs.
WC TW - up to 750 lbs. Heavy Duty Heavy Duty
WD GTW - Up to 12,000 lbs.
WD TW - Up to 1,200 lbs.
All Ranger Trail trailers that have a GVWR of more than 5000 lbs. must
use a Class IV hitch and 6000 lb. 2-inch trailer ball.
