FM MODE
1. - Set radio to 28.0000 Mhz. FM mode, Mic gain Max.
2. - Apply 1,000 Hz. tone to microphone and Adjust VR-4 ( FM DEV ) for a
maximum deviation of 5 Khz.
RF OUTPUT METER
1. - Set radio to 28.0000 Mhz. FM mode.
2. - Adjust VR-11 so that two LED bars are lit with 7 Watt output power.
