Rapid 5080e - Technical Specifications; Product Dimensions and Capacity; Staple and Adapter Details; Noise Level Information

36
GB
TECHNICAL SPECIFICATION
Complete designation Rapid 5050e Rapid 5080e
Width 120 mm 120 mm
Length 245 mm 245 mm
Height 157 mm 160 mm
Weight 2,2 kg 2,2 kg
Max. capacity (80g copying paper) 50 sheets 80 sheets
Max. stapling depth 50 mm 50 mm
Staple cassette type See the front of the cassette
No. of staples in the cassette 5000 5000
Adapter: Rapid 5050e/5080e
Power/Current, adapter See the data plate of the adapter
When stapling at maximum frequency, 50 staples/min (24000 staples/8h,
example in fig. 7), the equivalent noise level is 68 db(A).
Noise measurements carried out according to ISO 7779 with supplementary
proposal “Electrical staplers: Noise test code”.
A maximum 70 dB(A) equivalent noise level is a requirement in Germany in
general premises of such as, shops, airport check-in areas, receptions, and
similar.
Inlaga00AA 00-06-06, 11.2636
