6
connection clicks ➃.
• Loading of staples :
• Press the magazine locker
to unlock it from the
tacker body.
• Slide the rail
backwards.
• Insert staples/brads strip as shown on drawing
➇➈.
• Close the magazine by pushing the rail frontward
until locking.
• Power adjustment knob:
• Turn the power adjustment knob to adjust the
penetration depth of staples/brads to your need ➄.
• Operating the tool:
• Firmly press the safety yoke
against the work
piece until it is pushed in a few millimetres ➅.
• Briefly press the trigger and then release again
➆.
• Trigger is locked as long as you do not press
safety yoke against the work piece, thus preventing
accidental operation.
• Maintenance :
• Maintain your tool. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use.
• Remove the battery pack before cleaning the tool.
• If the tool/charger should fail despite the care taken
in manufacturing and testing procedures, repair
should be carried out by an after-sales service
centre for Rapid tools.
Operating instructions of charger:
• Do not use the tool whilst charging process.
Remove the battery out off the tool.
• Connect the charging point
of the charger into the
socket
off the battery ➉.
• Connect the charger
to the mains. x the LED
on the charger will turn red during the charge ➉.
• When the battery is full charged, the LED
off the
charger turn green ➉.
• Disconnect the plug out off the socket and
unplug the charger
from the mains.
• During the process of charging, the charger can
become warm: this is normal.
Protecting the environment:
Separate Collection. Do not dispose power
tools into household waste!
According to the European Directive
2002/96CE on waste electrical and electronic
equipment
• Tool: When the tool needs to be replaced, or if it is
of no further use it should be brought to a separate
collection centre for recycling.s
• Battery: the batteries are recyclables.
The battery can be recharged many times. At the end of
their useful life, run the battery down completely, then
remove it from the tool, and bring it to a local recycling
station.
Technical features:
: Power adjustment knob
: Trigger
: Battery pack
: Unlocking buttons
: Safety yoke
: Magazine locker
: Rail
: Magazine
: socket
: charging point
: charger
: LED
• Stapler/Nailer :
Dimension (l/w/h) : 220/60/195 mm
Weight (incl. battery) : 1,3 kg
Voltage : 7,2 V
No of shots per charge : ≈ 1500 cycles
Staples or brads :
- Rapid 53 : 6,8,10,12,14 mm
- Rapid n°8 : 15 mm
Noise information (EN 60745) :
- LpA= 79.3 dB(A), K=3 dB(A)
- LwA= 90.3 dB(A) K=3 dB(A)
(These values are tool characteristics. Noise at use can
be different and depends on the working environment,
the work piece and the intensity of operation.)
Vibration information (EN 60745) :
- Vibration : 1,214 m/s2 K=1,5 m/s2
(This value is a tool characteristic. The influence to the
hand-arm system at use can be different and depends
on the working environment and the gripping force.)
• Battery:
Voltage: 7,2 V
Capacity: 1300 mAh
Charging time: ≈ 2.5 hours
• Charger:
Input: 100-240V 50-60Hz
Output: 8,4 V d.c.
Intensity: 1000 mA
