RECEIVING. INSPECTION.
TRANS PORT.
CLEANING,,INSTALLATION
AND COMMISSIONING
The
support screws may
only be removed when
the machine
is switched
otf.
This means
that in addition
to the machine
control,
the main
switch in the
control cabinet
must
also be
switched off.
Secure
the main
switch with
a
padlock
whilst removing
the
support screws.
The
person
authorized
to
perform
this task
must keep
the key to the
padlock
on his
person.
The support
screws must
be removed
when the machine
is
switched off.
The main
switch and the
control
can then be
switched on with
the key-operated
switch.
The upper
cheek must
be opened
slightly. To
do this, firmly
press
the
left foot
pedal
of the
foot
switch
downwards
as
quickly
as
possible
beyond
the
pressure point
into
the
"Upper
cheek up"
position
so that
the
upper
cheek opens
a little further
(see
Section
5.2). The
hardwood
supports
insefted
to secure
the upper
cheek must
then be removed
again.
Great care must
be taken
in aligning the machine.
A
steel
plate,
approx.
0.5 inches
thick and
6 inches x 6
inches large
must be
fitted under each
side-post
foot
plate,
as a firm
support for the adjusting
screws. The machine
is
aligned with
the
adjusting screws,
located
in the side-post foot
plate.
A spirit
level
(with
the
assistance
of a tri-square)
or a frame
level can
be used
to check the
alignment and
is applied
to the
guiding
surfaces of the
upper-cheek
guide (on
the inside
of the
side
post),
as well as
in the middle
of the lower-cheek
suppott
(with
the
upper cheek
opened
by
approx. 12 inches),
aligning
the machine
exactly, both
vertically
and horizontally.
The
accuracy
of the spirit level
must be
at least 0.0012
inches
per
3
feet.
ATTENTION!
Particular care
must be taken
to
ensure that the
upper-cheek
guides
in both
side
parts
are
vedically
identical
on both sides.
