RAS MULTIBEND 9000 - Page 84

WORKING
WITH THE
MACHINE
you
can
now
use
a hardwood
lever, braced
against the
upper-cheek
guide,
to
press
out
the
machine
to the
righthand
side.
The upper-cheek
rails
may
be
very heavy
-
according
to
version
-
.
The
conesponding
weights are marked
in each
blade
at
the
right hand
side.
Prior
the each blade
changing'
the
authorized
people
must
be
consider these
weight
indica-
tion.
lt is
therefore
absolutely
necessary
to
ensure
that
enough
people
are
available
to changethe
rails.
Each
person
should
not lift
more
than
aPprox.
66 lbs
(
30 kg).
At divided
goat
foot bladeswith
coresponding
holding
blade,
prior
to
the
blade
changing
the
paft pieces
must be
taken
off
the
hotding
blade
in order
to
reduce
the
blade weight
to
a
minimum.
The
weight
of the
holding
blade
is marked
at the
right
hand
side
of the blade
and
this
only
corresponds
to
the
holding
blade
without
build-in
pad
pieces.
When
removing
the rail,
it is advisable
to
pull
it
out on
the
right-hand
side first until
the
rail
is
basically
only held
on the
lefi-hand
side
by its retainer.
The
new
rail is
installed
in reverse
order,
i.e. the
rail is f irst
inserted
into its retainer
on the left-hand
side,
then
swung
into
place
on
the right-hand
side, finally
being
brought
into
the working
position
by
sliding
to the left
as far
as the
stop.
AT
TION!
RAS
74.20-40
MULTIBEND
9OOO
Every
time
a
rail is replaced
on
the upper
cheek,
the
safety
limiter
for
the bending
angle must
be readjusted
in accord-
ance
with Section
6.2.3 "ADJUSTING
THE
SAFEW
DEVICE
FOH
MAX.
BENDING
ANGLE".
Apart
from
this,
the hardwood
blocks
placed
underthe
uppercheek
must
be removed
again.
6-16
September
7,
1993
