Technical Specification - Rascal Vantage X Scooter
Wheelchair type Class Class A, B or C Class C
Department of Transport Class Class 1 2 or 3 Class 3
Overall dimensions fully assembled length x width x height mm (in) 1200 (47.24) x 585 (23.03) x 955 (37.59)
Dimensions seat and tiller folded length x width x height mm (in) 1200 (47.24) x 585 (23.03) x 755 (29.72)
Maximum carrying capacity@ 7˚ incline* kg (lbs) 149.7(330)
Maximum carrying capacity @ 10˚ incline* kg (lbs) 113.4 (250)
Mass (weight) including 50 Ah batteries kg (lbs) 85.8 (189.15)
Mass (weight) of chassis (heaviest part) w/50 Ah batteries kg (lbs) 72.6 (160.05)
Standard battery voltage and capacity volts and ampere hours 12V / 50Ah x 2
Type of seat Swivel seat with folding backrest and adjustable arms
Mass (weight) of swivel seat kg (lbs) 12.6 (27.7)
Wheel/tyre dimensions front mm (in) 71 x 63.5 - 101 (2.8 x 2.5 - 4)
Wheel/tyre dimensions rear mm (in) 76.2 x 76.2 - 101 (3 x 3 - 4)
Maximum speed km/h (m.p.h.) 9.65 (6)
Minimum braking distance from maximum speed m (ft) 1.4 (4.59)
*Range with standard battery option km (miles) Up to 42 (26)
The turn-around width m (ft) 1.4 (4.59)
The maximum safe slope degrees of slope 10 / 7˚ * See carrying capacity!
Do not exceed the scooter may topple!
The maximum climbing ability facing upwards degrees of slope 10 / 7˚ * See carrying capacity!
Do not exceed the scooter may topple!
Ground clearance mm (in) 65 (2.6)
Maximum obstacle climbing ability mm (in) 76 (3)
Maximum safe descendable kerb height mm (in) 76 (3)
Force to operate Accelerator control Newtons (lbs) 2 (0.45)
Force to operate Freewheel lever Newtons (lbs) 45 (10.1)
Force to operate Emergency brake lever Newtons (lbs) 60 (13.5)
Ambient operating temperature range °C (°F) 2 (35.6) to 40 (104)
This scooter meets the relevant requirements of ISO 7176:14 2008 *Range on full charge and flat ground. Due to a policy of continual improvement, Electric
Mobility reserves the right to change specifications without prior notice.
