Rasonic RTP-B33TC - Product Identifications; Component Labels and Lid Removal

– 12 –
RTP-B33TC / RTP-W33S / RTP-B43TC / RTP-W43S 電熱水瓶 Thermo Pot
3. Product Identifications
Inner pot
Dispensing spout
Air-pressure pump
Steam vent
Lid opening lever
Air-pressure lock
Drain position
Full water level
Power connector
Press the upper lid release button,
then lift the lid at angle 45 degree
and pull it out.
Method to Detach the Lid
Upper Lid
Release
Button
Cup push button
Water level
Water lter
Rotary base
Inner pot
Dispensing spout
Air-pressure pump
Steam vent
Lid opening lever
Air-pressure lock
Drain position
Full water level
Power connector
Press the upper lid release button,
then lift the lid at angle 45 degree
and pull it out.
Method to Detach the Lid
Upper Lid
Release
Button
Cup push button
Water level
Water lter
Rotary base
Panel of RTP-B33TC and RTP-B43TC
Panel of RTP-W33S and RTP-W43S
