XII. SPECIFICATIONS
1. R100 R160 R180-3 R200 R210 R225
1) MAIN SPECIFICATION
Model
Specication
R100 R160 R180-3 R200 R210 R225
L×W×H (mm)
310×290×300 390×320×345 / 445×320×345(Electric)
Dry Weight (kg) 10 16/18(Electric)
Gasoline Engine
Type
4-Stroke,OHV,Single Cylinder
Displacement(ml) 98 163 179 196 212 223
Compression
Ratio
8.5:1 8.4:1
Bore × Stroke(mm) 56×40 68×45 65×54 68×54 70×55 70×58
Maximum Output
Power (kW/r/min)
1.8/3600 3.4/3600 3.5/3600 4.0/3600 4.1/3600 4.3/3600
Maximum Torque
(N.m/r/min)
4.7/2500 9.0/2500 9.5/2500 11/2500 12/2500 13/2500
Cooling System Forced Air-cooled
Ignition System Transistonized Magneto Ignition(TCI)
Spark Plug E7TC BP6ES(NGK)/F6RTC(NHSP)/F6TC/F7RTC/F7TC
Lubrication
System
Forced Splash
PTO Shaft
Rotation
Counterclockwise
DATA ADJUSTMENT:
Items Technical Data
Spark Plug Clearance 0.7- 0.8mm
Valve Clearance (Cold Engine) Intake: 0.10-0.15mm Exhaust: 0.15-0.20mm
