33
·
SPECIFICATIONS
DATA ADJUSTMENT:
Items Technical data
Spark Plug Clearance 0.7-0.8mm
Valve Clearance (Cold Engine) Intake: 0.10-0.15mm Exhaust: 0.15-0.20mm
2) TORQUE OF IMPORTANT BOLTS:
Items Specications
Torque Valve
N·m Kg·m
Connection-Rod Bolt M8×1.25(special) 15 1.5
Cylinder Head Bolt M10×1.25 45 4.5
Flywheel Nut M16×1.5(special) 95 9.5
Lock Nut Of Rocker Arm Shaft M6×0.75 10 1.0
Rocker Arm Stud M8×1.25(special) 24 2.4
Crankcase Bolt M8×1.25 28 2.8
