ELECTRIC DIAGRAM
Bl BLACK
Y YELLOW
G GREEN
IGNITION COIL
ENGINE SWITCH
SPARK PLUG
Bl
Y
Y
Bl
Y
OIL SENSOR
OIL PROTECTOR
2.No Electric Starter Engine With Oil Protection System
