Rato R2200 User Manual

APPENDIX
75
APPENDIX
TORQUE
No．
Item
Size
Performance Grade
Torque（N·m）
1
Fuel tank Assembly
M6×25
8.8-B
10±2
2
Leveler Assy.oil
Assembly
M5×10
8.8-B
6±1
3
Muffler Assy
M8×16
8-A
24±2
4
M8×30
8.8-A
26±2
5
Muffler outer cover
M6×12
8.8-B
10±2
6
Muffler side cover
M6×12
8.8-B
10±2
7
Muffler shield
M6×12
8.8-A
10±2
8
Muffler block
M8×12
8.8-A
20±2
9
Panel Subassembly
control
M6×12
8.8-B
10±2
10
Panel control
M4×10
8.8-A
2.5±0.5
11
Case panel rear
M4
8.8-A
2.5±0.5
12
Bracket motor
M6×12
8.8-B
10±2
13
Stator comp.
M6×180
8.8-A
10±2
14
Brush Subassembly
carbon
M5×12
8.8-A
5±1
15
Rotor comp.
M10×265
8.8-B
44±2
16
Regulator voltage
M5×12
8.8-A
6±1
17
band
M5×14
8.8-A
5±1
18
Engine
M10
8-A
30±2
19
Cushion Engine frame
M8
8-A
20±2
20
Seat Engine frame
shock absorption
M6×10
8.8-B
10±2
21
M6
8.8-B
10±2
