• Specifications
1) Power supply: 24V,36V,48V
2) Rated current: 10mA
3) Max current: 30mA
4) Leakage current after power off: <1uA
5) Current supply to controller:50mA
6) Working Temperature：-10~60℃
7) Storage temperature：-20~70℃
• Error code definition
When an error appears, GD06 will notice users by different codes,
please refer to table 1 for different codes:
Code (Decimal) Signification
0
Normal
Low Battery level
Communication failure
current sensor fault
Throttle failure
Failure of motor phase line
Motor hall failure
Brake abnormity
6
30
21
22
23
24
25
