Rave RSS-WB - Device Ports and Remote Control; Physical Interface Overview; Remote Control Functions

AUX IN NET BT
IR
USB
AUX
AUX
I
I
N
N
AUX
AUX
OUT
OUT
LAN
LAN
USB
USB
5V/1A
5V/1A
B C D E F
G H I J K
L
B
IR: IR Receiver Port
C
AUX IN: Aux Source Mode
D
NET: Wi-Fi Source Mode
E
BT: Bluetooth Source Mode
F
USB: USB Source Mode
G
LAN: RJ45 Ethernet Port
H
USB: USB Port (1024 track limit).
I
AUX IN: Stereo 3.5mm Input
J
AUX OUT: Stereo 3.5mm Output
K
5V/1A: 5V/1A Micro USB Input
L
RESET/SLEEP: short press sleep on/off
long press Bluetooth (reset) pairing
