CALIBRATE ISO RAVEN STEERING CONTROLLER | CR7 AUTOSTEERING | RAVEN EUROPE GENERIC
PAGE 10/24 | Calibration manual | 016-8000-015EN | Rev. A
Measure and enter the value from the
ground to the Antenna.
Remember this value! Later in the
configuration it needs to be entered
again.
Press next step.
Measure and enter the value from the rear
axle to the front axle.
Remember this value! Later in the
configuration it needs to be entered
again.
Press next step.
Setup the GPS Differential needed for the
system. In this example the Raven 600S is
configured for SBAS.
It is possible to choose a Differential
Sattelite. When this one is on Auto, the
receiver will select the strongest one.
When selecting the box underneath
Differential Source, it is possible to select
from GL1DE, SBAS, Satellite GS or RTK.
