CALIBRATE ISO RAVEN STEERING CONTROLLER | CR7 AUTOSTEERING | RAVEN EUROPE GENERIC
PAGE 18/24 | Calibration manual | 016-8000-015EN | Rev. A
When steering the steering wheel, the
disengage status should move to red. This
means in practice, the autosteer shuts off
when turning the steering wheel at this
typical rate. It is possible to change the
calibrated value by pressing on the value
and enter another value.
Press next step.
A summary of the calibration is shown. Press
the checkmark to enter the main screen of
the UT from the ISO Raven Steering
Controller.
This is the main menu of the UT from the
ISO Raven Steering Controller.
Press on the settings button (button with the
gears), in the right side of the menu.
The Profile name is now standard on ‘Front
Steered Tractor’.
The name of this Profile can be changed to
the right name by pressing on ‘Change
Profile’.
