CALIBRATE ISO RAVEN STEERING CONTROLLER | CR7 AUTOSTEERING | RAVEN EUROPE GENERIC
PAGE 8/24 | Calibration manual | 016-8000-015EN | Rev. A
The system is expecting a Steering Partner.
For an ISO Steer Ready tractor, the specific
brand will appear.
For a complete Raven Europe Steering
system, the steering partner is called ‘SBG
HDU’ (see figure on the right).
Select ‘next step’.
The Steering System needs GPS input to
work. In this step it is needed to select the
GPS receiver. Select the ‘Receiver Selection’
tab to select a receiver.
When a complete Raven Europe
Autosteering kit is mounted, a Raven 600S
receiver is also mounted. Select Raven 600S
to make sure configuration is in the right
way.
600S is selected. Press next step.
