RG55R Operation • Service • Maintenance
28
Operation
Blade Transition for Transporting
The RG55R comes equipped with a 50 1/2” wide blade.
For convenience of transporting through gates, or to load
and unload on and off a trailer, the blade has wings (16) that
can swing in to be only 34 1/2” wide.
To swing the blade wings inward, pull the clevis pins (17)
located on the back side of the blade. Simply turn the wings
inward, reinstall the clevis pins at holes (18) located on top
of blade to ensure they stay folded in.
18
16
17
