Trigger Connection
A. Connect the P-interface cable to the generator
X-ray Generator Connection
Connect the P-interface cable between the AGI box and X-ray
generator.
A. Wired Mode 1 : P-interface cable mode
Operating description
Make
assurance
doubly sure
SIGNAL RATING
before connection.
