Raymarine Dragonfly-4 User Manual

9.9Chartsettingsmenu—cartography
compatibility..............................................................83
9.10Chartselection...................................................84
9.11ChartDetail........................................................84
9.12Highresolutionbathymetry.................................85
9.13Chartorientation................................................85
9.14T extandSymbolsize..........................................86
9.15Boatposition......................................................87
9.16Communitylayer................................................87
9.17Sonarlogging.....................................................88
9.18COGVector.......................................................88
9.19DeepWater.......................................................89
9.20Chartobjects.....................................................89
9.215MSystemsettingsmenu..................................90
Chapter10Mobileapplications..........................91
10.1Wi-Fish
TM
mobileapp.........................................92
10.2ConnectingWi-Fi—Prodisplays........................92
Chapter11Tools&Settings...............................93
11.1SystemSettingsmenu........................................94
11.2Alarms.............................................................100
11.3Backupandreset.............................................103
11.4Wi-FiSettings...................................................105
Chapter12Maintenance...................................107
12.1Serviceandmaintenance.................................108
12.2Productcleaning..............................................108
12.3Transducercleaning.........................................109
Chapter13Troubleshooting..............................111
13.1Troubleshooting................................................112
13.2Poweruptroubleshooting..................................113
13.3GPStroubleshooting.........................................114
13.4Sonar/DownVisiontroubleshooting...................115
13.5Miscellaneoustroubleshooting...........................117
Chapter14Technicalsupport..........................119
14.1Raymarinecustomersupport............................120
14.2Learningresources...........................................120
Chapter15Technicalspecication..................121
15.1T echnicalspecication......................................122
Chapter16Sparesandaccessories................125
16.1Spares&Accessories......................................126
6
Dragony-4/Dragony-5/WiFish

Raymarine Dragonfly-4 Specifications

General

Display Size	4.3 inches
Resolution	480 x 272 pixels
GPS	Yes
Waterproof	IPX6 and IPX7
Power	12V DC
Transducer	Included
Power Supply	12 V DC
Max Depth	600 feet (DownVision)
Power Output	300W RMS
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to 70°C
Weight	0.68 kg
Sonar	CHIRP DownVision
