SPX-10 Hydraulic Installation Guide for Verado systems 5
Initiating the system
WARNING: Carry out initiation procedures before use
Do not use the steering system to steer the boat until the following
initiation procedures have been completed.
Before the steering system is used to steer the boat, you must:
• Bleed the system.
• Check the system for leaks.
• Commission the system.
Mercury Helm
Mercury steering actuator
E R T L P
Type 1 Pump
B
R
A
Mercury Hydraulic
Pump
Return line
Existing Mercury hoses
SmartPilot Verado hoses
Reservoir
HP line
1' (305 mm)
3' (915 mm)
Hydraulic circuit
D10728-1
L
R
1
2
6
10
12
8
4
3
5
9
11 &13
7
