Pump drilling template

D8590-1

Clearance hole

Drill 6.5 mm (17/64 in)

Clearance hole

Drill 6.5 mm (17/64 in)

Type 1 pump:

Front

Remove shaded areas only

89 mm (3 1/2 in)

87077_1.book Page 7 Monday, November 26, 2007 2:24 PM
