2. MEASURE MODE
After an oset adjustment, the instrument is in MEASURE MODE. The displayed values are updated after each
exposure, or continuously after 4 seconds of fluoroscopy.
kVp kVp (for the R/F high, RAD or DENT high sensor at adequate signal levels) or kV (R/F
low or DENT low).
(Not available on RaySafe Solo Dose.)
Dose Gy (Air kerma, free in air) or R (Exposure)
Dose rate Gy or R per s, m or h
Time ms, s
HVL mm Al (only with optional HVL kit)
Pulses pulses
Total filtration mm Al (included in the optional HVL kit)
mAs mAs (requires RaySafe Solo R/F with mAs)
mA mA (requires RaySafe Solo R/F with mAs)
3. SETUP MENU
Press SELECT to enter the SETUP MENU (from MEASURE MODE) and STEP to step between setup
parameters.
11
RaySafe Solo User Manual – R/F Measurement
