8-4
HSB Series CRT Display
8.2 Unpacking and Inspecting the Components
Unpack your system carefully, to prevent damage to the equipment. It is good
practice to save the carton and packing for future use, in case you need to return
any units for service. Check that you have all the correct system components.
These depend on your system package, as detailed in the table below.
Check that the safety seal, fitted across one of the display cover fixing screws
on the rear of the unit, is in place and not damaged.
Item Part No. Supplied with: Option for:
77
77
7"
CRT Display CRT Display
CRT Display CRT Display
CRT Display M92660 R70 -
M92672 R70RC -
77
77
7"
CRT Display Accessories CRT Display Accessories
CRT Display Accessories CRT Display Accessories
CRT Display Accessories
Sun cover (light grey) E55014 Both -
Viewing Hood E55013 Both -
1010
1010
10"
CRT Display CRT Display
CRT Display CRT Display
CRT Display M92661 R80 -
M92673 R80RC -
1010
1010
10"
CRT Display Accessories CRT Display Accessories
CRT Display Accessories CRT Display Accessories
CRT Display Accessories
Sun cover (light grey) E55022 Both -
Viewing Hood E55021 Both -
Fuses: 6.3A anti-surge E55016 All -
Handbook, Radar/Chart 81153 All -
Quick Reference Card, Radar 86042 All -
Quick Reference Card, Chart 86045 R70RC, R80RC -
Chart Upgrade Kit
R70 to R70RC & R80 to R80RC E55012 - R70, R80
Mounting bracket assy. 7" E55015 Both -
Mounting bracket assy. 10" E55023 Both -
Trunnion knobs (x2) W145 All -
Flush mount kit (7" and 10") E55024 R80, R80RC R70, R70RC
Power cable W144 All -
Seatalk cable assembly
Flat moulded plugs both ends:
1 m (3 ft 3 in) D284 - All
3 m (9 ft 9 in) D285 - All
5 m (16 ft 3 in) D286 - All
9 m (29 ft 3 in) D287 - All
Flat to male round connector:
0.3 m (1 ft) D187 - All
Flat to female round connector:
0.3 m (1 ft) D188 - All
Flat moulded plug one end only:
1 m (3 ft 3 in) D229 - All
Ferrite clamp R55007 - All
Unpacking and
Inspecting the
Components
