E-2
HSB Series CRT Display
+
SeaTalk
SeaTalk
Power
(SeaTalk)
NMEA
12/24V Supply 12/24V Supply
Compass Power/NMEA Data Connections
SeaTalk
GPS
Course Computer
Course Computer
Distribution Panel
D4123-1
Scanner
SeaTalk
Typical SeaTalk System
SeaTalk, Yellow
SeaTalk, Red
SeaTalk, Grey (screen)
NMEA IN, negative (---)
NMEA IN, positive (+)
Yellow Black
(screen)
Red
NMEA IN
Active Compass
ST80 Active Compass
Radar Display
(Power and NMEA
Input Connector)
NMEA
+––
+
–
CRT Display
DISPLAY
RANGE
MARKS
VRM/EBL
ALARMS
GAIN
SEA
MULTI
MOB
ENTER CLEAR MENU POWER
Appendix F:
Connecting an
Active Compass
