Preface
This handbook describes the following Raytheon HSB Series Display systems:
System Display Scanner Chartplotter
Pathfinder Radar R70, R80 Yes No
Combined Pathfinder
Radar/Chartplotter R70RC, R80RC Yes Yes
Repeater Display R70, R80 No No
R70RC, R80RC No Yes
Notes: Radar systems are supplied with an appropriate Raytheon scanner unit
and inter-connecting cable. Details for installing the scanner are described in
the Pathfinder Radar Scanner Owner’s Handbook.
The chartplotter display unit includes a cartridge holder assembly which
contains two slots for C-MAP NT chart cards.
This handbook contains very important information on the installation and
operation of your new equipment. In order to obtain the best results in operation
and performance, please read this handbook thoroughly.
Raytheons Product Support representatives or your local dealer will be
available to answer any questions you may have.
Warranty
To register your HSB Series Display unit ownership, please take a few minutes
to fill out the warranty registration card found at the end of this handbook. It is
very important that you complete the owner information and return the card to
the factory in order to receive full warranty benefits.
EMC Conformance
All Raytheon equipment and accessories are designed to the best industry
standards for use in the leisure marine environment.
The design and manufacture of Raytheon equipment and accessories conform
to the appropriate Electromagnetic Compatibility (EMC) standards, but correct
installation is required to ensure that performance is not compromised.
