Owner manual
1. Remove the pedals. Use the 15mm wrench.
2. Remove the left crank arm. Use the cassette extractor
to loosen the centre screw and remove it. Use the same tool
to remove the crank arm.
3. Take out the PAS. Once removed the left crank arm,
the Pedal Assisted Sensor is next. Disconnect the PAS cable
and remove it by pulling.
4. Go to the opposite side and repeat the process.
5. Remove the BB set. Use the Bottom bracket head and
an adjustable spanner to untighten the BB set. Remove
both sides.
6. Now take the new Torque Sensor.
