7. Remove the fixed cap of the torque sensor. Place
it on the left side (non-driving) and lock it with the Bottom
bracket tool.
8. Introduce the Torque sensor. First run the cable
through the middle hole, then introduce the full body and
lock it with the bottom bracket tool.
9. Connect the Torque sensor. Using the cable extension
from the Torque sensor kit, connect the Torque sensor cable
to the plug where the PAS was connected before.
10. Install the new chainring from the Torque sensor
kit. Attach the chain to the plate and place the lock nut, use
the Bottom bracket head to tighten it.
11. Place both crank arms. Lock them with the crank arm
nuts, use an M8 Allen key.
12. Install back the pedals. Use the 15 mm wrench.
