ASSEMBLY AND SET-UP
q Attaching Handlebars
q Inflating Tire
1
Inflate front tire to PSI indi-
cated on sidewall of tire.
Note: The pressurized air
supplies found at gasoline
stations are designed to inflate
high-volume automobile tires.
If you decide to use such an
air supply to inflate the tire,
first make sure the pressure
gauge is working, then use very
short bursts to inflate to the
correct PSI. If you inadvertently
over-inflate the tire, release the
excess pressure immediately.
3 Adjust tension of the quick
release to where you can close
lever all the way to secure stem.
q Attaching the Seat (if applicable)
2
Unscrew four screws on
middle of deck.
3 Place seat post on deck and
secure .
1 Attach seat to seat post.
3
Note: Make sure the cables/
wires are out of the way before
inserting the stem in the fork.
1 2
To Next Page
