Razor E100S User Manual

8
TROUBLESHOOTING GUIDE
Sometimes the scooter
doesn’t run, but other
times it does
Scooter makes loud
noises or grinding sounds
Problem Possible Cause Solution
Loose wires or connectors
Motor or electrical switch
damage
Chain is too dry
Check all wires around the motor and all connectors to make sure
they are tight.
Contact your local Razor authorized service center for diagnosis and
repair.
Apply a lubricant such as 3 in 1
TM
or Tri-Flow
TM
to the chain.
For more helpful troubleshooting guides, visit us at www.razor.com.
Need Help? Call 0118 973 6222.

Razor E100S Specifications

General

Type	Classic scooter
Foldable	No
Kickstand	Yes
Maximum speed	18 km/h
Product color	Black, Red
Number of wheels	2 wheel(s)
Front brake system	Disc
Recommended gender	Any gender
Maximum load weight	54 kg
Recommended age (min)	8 yr(s)
Battery voltage	12 V
Number of batteries supported	2

Weight and Dimensions

Depth	857 mm
Width	420 mm
Height	892 mm
