Razor E90 User Manual

1
2
3
4
8
12
14
15
10
13
11
9
19
7
5
6
16
17
18
20
8
Need Help? Visit our web site for replacement parts and product support at www.razor.com or call toll-free at
866-467-2967 Monday - Friday 8:00 AM - 5:00 PM Pacific Time. Please have the product I.D. code (located on the
bottom of the frame) available for better assistance.
E90/ACCELERATOR ELECTRIC SCOOTER PARTS
Keep your scooter running for years with genuine Razor parts. Visit our website or e-mail us for more information on spare part availability.
(Specifications subject to change without notice.)
1. Handlebar grips (right/left)
2. Push button throttle
3. Handlebar Stem
4. Collar clamp
5. Headset (upper/lower)
6. Front fork w/limiter
7. Front wheel complete (See pg. 5 for hardware sequence)
8. Battery tray
9. Control module
10. On/off switch
11. Charger port
12. Kickstand
13. Chain tensioner
14. Motor (12V/100W)
15. Rear fender brake
16. Rear wheel complete (See pg. 5 for hardware sequence)
17. Chain
18. Chain guard
19. Battery (1-12V/7Ah) w/fuse
20. Deck plate

Razor E90 Specifications

General

Foldable	No
Wheels type	Solid wheels
Maximum speed	14.5 km/h
Product color	Orange, White
Built-in display	-
Maximum load weight	100 kg
Recommended age (min)	8 yr(s)
Battery life	50 min
Battery voltage	12 V
AC adapter included	Yes

Weight and Dimensions

Depth	780 mm
Width	350 mm
Height	830 mm
Weight	9800 g
