6
REPAIR AND MAINTENANCE
WARNING: Practice in
an open area free from obstacles
until you are familiar with the brake
function. DO NOT RUN OVER ANY
OBJECT AS IT COULD DAMAGE THE
BRAKE OR DRIVETRAIN.
Adjusting the Brake
The brake lever is fitted with a cable adjuster to compensate for cable stretch and/or to fine tune the lever movement to
brake engagement.
1 To adjust the brake, thread the
adjuster in or out 1/4 to 1/2 turns
until the desired brake adjustment
is attained.
2 If the adjuster is threaded
outward and the brake still has
too much slack, use the auxiliary
adjuster at the rear brake for
additional adjustments.
Note: When properly adjusted,
the brake lever will have
approximately 3 mm of free play
before the brake engages.
Replacing the Wheels
Tools Required: 13 mm Allen Wrench (Front Wheels), 24 mm Allen Wrench (Rear Wheels)
Front and rear wheel installation and removal are the same.
Loosen
Tighten
1 To remove a wheel, remove the
self-locking nut (13 mm socket or
wrench required for front wheels,
24 mm for the rear wheels). Tap the
wheel to remove.
2 Front Wheel Installation:
To replace a front wheel, make sure
the bearings are seated and the
center spacer is installed. Position
the wheel with the Razor logo
facing outward.
Install the washer and tighten the
self-locking nut securely.
3 Rear Wheel Installation:
To replace a rear wheel, make sure
the key is properly seated in the
rear axle and aligned with the key in
the wheel. Position the wheel with
the Razor logo facing outward.
Install the washer and tighten the
self-locking nut securely.
Note: The Ground Force Drifter
wheels must be replaced
when worn down to the wear
indicator line.
Note: Practice drift riding only in
wide open areas clear from curbs,
parking blocks and other obstacles.
Impacting the wheels against
any hard surface can damage the
wheels. Wheels are not covered
under your limited warranty.
WARNING: Failure to
properly adjust and tighten the
screws, nuts and bolts that affix
the wheels can cause you to lose
control and crash.
Turn power switch OFF before conducting any maintenance procedures.
Read the instructions
Remove charger plug
Turn the power switch OFF
Secure the unit under repair
Exercise caution around
exposed parts
Contact Razor customer service
if unsure about any repair
or maintenance
Testing the Brake
To use the brake, squeeze the lever to increase the pressure on the brake. The brake lever is fitted with a cable adjuster
to compensate for cable stretch and/or to fine-tune the lever movement to brake engagement. If brake is not engaging
properly, follow instructions for adjusting the brakes.
Note: The brake lever contains a
safety switch to cut off power to the
motor when the brake is applied. In
an emergency, applying the brake
will always stop the product from
moving. Do not disable or replace
this lever with anything other than a
genuine Razor replacement part.
