Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer Service
contact information is listed at the back of this manual.
ASSEMBLY AND SET-UP
Assembling the T-bar
No tools required.
1 Pull the folding release lever away
and up to raise the front fork into the
upright position.
2 Remove the “E” shaped fixed pin from
the front fork assembly.
3 Slide the steering clamp cover onto
the T-bar.
4 Insert the T-bar into the front fork
assembly using your thumb to depress
the button on the T-Bar until it “locks”
into place.
5 Insert the “E” shaped fixed pin into the
open hole on the front fork assembly to
secure T-bar.
6 Slide the steering clamp cover down
and over the “E” shape fixed pin.
