Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
ROLLIE/ROLLIE DLX PARTS
10
1
3
4
4
1
5
8
15
12
15
2
16
9
13
14
11
11
10
6
6-1
7
16
Keep your scooter working for years with genuine Razor parts. Visit our website or e-mail us for more information on spare part availability. (Specifications
subject to change without notice.)
1. Handlebar Grips (Set of 2)
2. T-Bar
3. Collar Clamp
4. Seat Post
5. Seat
6. Seat Clamp
6-1 Seat Lock Knob
7. Pedal
8. Brake Pads
9. Deck Plate
10. Truck
11. Light-Up Front Wheels
12. Rear Wheel
13. Batter y Tray
14. AAA Batteries (x3)
15. Rear Axle Bolts
16. Front Axle Bolts
