Razor TURBO JETTS User Manual

B
A
B
A
B
A
B
A
Non-Motorized Side
Motorized Side
5 Follow the direction of the arrow
to insert foot. Place foot in Turbo
Jetts and push the frame from
both sides until it clicks into place
snuggly fitting width of shoe.
Note: Adjustment must be done
while wearing recommended
appropriate footwear.
6 Pull tab down to secure the
strap. Align and press together hook
and pile sides of the strap. Make
sure it is completely secure.
4
ASSEMBLY AND SET-UP
Adjusting the Turbo Jetts
WARNING: Failure to properly adjust the Turbo Jetts may cause the user to lose control and fall.
2 To make strap shorter: Pull
the outer strap first (B), then the
inner strap (A).
2 To make strap shorter: Pull
the outer strap first (B), then the
inner strap (A).
1 To make strap longer: Pull the
inner strap first (A), then the outer
strap (B).
1 To make strap longer: Pull the
inner strap first (A), then the outer
strap (B).
5 Center stap pad and pull stap
snug.
Note: Adjustment must be done
while wearing recommended
appropriate footwear.
3 Press the button and pull the
frame to its maximum width.
3 Press the button and pull the
frame to its maximum width.
6 Pull tab down to secure the
strap. Align and press together hook
and pile sides of the strap. Make
sure it is completely secure.
4 Place foot in Turbo Jetts and
push the frame from both sides until
it clicks into place snuggly fitting
width of shoe.
4 Place foot in Turbo Jetts and
push the frame from both sides until
it clicks into place snuggly fitting
width of shoe.

Razor TURBO JETTS Specifications

General

Type	Electric heel wheel roller skates
Gender	Unisex
Boot type	-
Coloration	Monochromatic
Wheel size	50 mm
Wheels color	Black
Product color	Black, Red
Adjustable size	Yes
Target audience	Children
Wheels material	Polyurethane
Maximum load weight	80 kg
Recommended age (min)	9 yr(s)
Maximum speed	16 km/h
Motor power	80 W
Battery voltage	16 V

Weight and Dimensions

Depth	274 mm
Width	196 mm
Height	137 mm
Weight	2300 g
