RBI DOMINATOR Series - Page 43

DOMINATOR INSTALLATION AND OPERATION INSTRUCTIONS Page 43
23 Flue Outlet Assembly 70-2736 1
70-2737 1
70-2738 1
70-2739 1
70-2740 1
70-2741 1
70-2742 1
70-2742.1 1
70-2743 1 1
24, 25, Tile Kit 05-0202 1
27 05-0203 1
05-0204 1
05-0205 1
05-0206 1
05-0207 1
05-0208 1
05-0209 1
05-0210 1
05-0211 1
26 End Refractory Panel, Right 05-0058 1 1 1 1 1 1 1 1 1 1
End Refractory Panel, Left 05-0107 1 1 1 1 1 1 1 1 1 1
28 Manifold 10-0465 1
10-0466 1
10-0467 1
10-0468 1
10-0469 1
Left Manifold 04-0630 1
04-0631 1
04-0632 1
04-0633 1
04-0634 1
Right Manifold 04-0650 1
04-0651 1
04-0652 1
04-0653 1
04-0654 1
29 Main Orifi ce, NG 10-0087 3 7 9 11 13 17 19 25 27
Main Orifi ce, LP 10-0088 3 7 9 11 13 17 19 25 27
Main Orifi ce, NG 10-0115 5
Main Orifi ce, LP 10-0116 5
NS Pilot Orifi ce, NG 10-0089 1 1 1 1 1 1 1 1 1
Pilot Orifi ce, LP 10-0090 1 1 1 1 1 1 1 1 1
Pilot Orifi ce, NG 10-0093 1
Pilot Orifi ce, LP 10-0094 1
30 Burner Tube 10-0275 3 5 7 9 11 13 17 19 25 27
Burner Tube w/hole for Pressure Switch 70-2898 1 1 1 1 1 1 1 1 1 1
Pilot Tube Assembly (tubing and fi ttings) 70-2896 1 1 1 1 1 1 1 1 1 1
NS Burner Gasket 06-0020 4 6 8 10 12 14 18 20 26 28
31 Spark Ignitor
16-0327* 1 1 1 1 1 1 1 1 1 1
(*prior to 0206 - must order w/cable 44-0056)
NS Ignition Cable Assembly 44-0056 1 1 1 1 1 1 1 1 1 1
Ref # Name of Part Part # 300 400 600 750 900 1050 1350 1500 1950 2100
