DOMINATOR INSTALLATION AND OPERATION INSTRUCTIONSPage 44
NS Heat Exchanger Assembly (Copper) 70-2826 1
(Cast Iron Headers) 70-2827 1
70-2828 1
70-2829 1
70-2830 1
70-2831 1
70-2832 1
70-2833 1
70-2834 1
70-2835 1
Heat Exchanger Assembly (Copper) 70-2846 1
(Bronze Headers) 70-2847 1
70-2848 1
70-2849 1
70-2850 1
70-2851 1
70-2852 1
70-2853 1
70-2854 1
70-2855 1
NS Heat Exchanger Assembly (Cupronickel) 70-2836 1
(Cast Iron Headers) 70-2837 1
70-2838 1
70-2839 1
70-2840 1
70-2841 1
70-2842 1
70-2843 1
70-2844 1
70-2845 1
Heat Exchanger Assembly (Cupronickel) 70-2856 1
(Bronze Headers) 70-2857 1
70-2858 1
70-2859 1
70-2860 1
70-2861 1
70-2862 1
70-2863 1
70-2864 1
70-2865 1
32 Tube Bundle (Copper) 70-2901 1
70-2902 1
70-2903 1
70-2904 1
70-2905 1
70-2906 1
70-2907 1
70-2908 1
70-2909 1
70-2910 1
Tube Bundle (Cupronickel) 70-2911 1
70-2912 1
70-2913 1
70-2914 1
70-2915 1
70-2916 1
70-2917 1
70-2918 1
70-2919 1
70-2920 1
34 V Baffl e Hold-Down 03-2021 2 2 2 4 4 4 4 8 8 8
NS Heat Exchanger Support Channel 03-2022 1
03-2023 1
03-2024 1
35 O Ring, Inlet/Outlet & Return Headers 06-0001 20 20 20 20 20 20 20 20 20 20
36 Stud, Inlet/Outlet & Return Headers 57-0225 12 12 12 12 12 12 12 12 12 12
37 Nut, Inlet/Outlet & Return Headers 57-0491 12 12 12 12 12 12 12 12 12 12
38 Return Header, Bronze 01-0018S 1 1 1 1 1 1 1 1 1 1
Return Header, Cast Iron 01-0023S 1 1 1 1 1 1 1 1 1 1
Ref # Name of Part Part # 300 400 600 750 900 1050 1350 1500 1950 2100
