RBP RX3 Series - Page 3

RBP-1128B-RX3
RBP-1128SS-RX3
Page 3 of 4 4/17/19(AL)
13000 Temple Ave. City of Industry, CA 91746 1-877-519-9090
(Fig. 2) Driver/Left front mounting location
(Fig. 3) Driver/Left mounting bracket
Factory 8mm threaded
insert in body panel
Front
(Fig. 5) Driver/Left bracket mounted
Fig. 4
8mm hex bolts
8mm lock washers
8mm flat washer
Front
