RBP RX3 Series - Page 4

RBP-1128B-RX3
RBP-1128SS-RX3
Page 4 of 4 4/17/19(AL)
13000 Temple Ave. City of Industry, CA 91746 1-877-519-9090
(Fig. 6) Driver/Left 2nd mounting location
Factory 8mm threaded
insert in body panel
Front
Factory 8mm threaded
insert in body panel
(Fig. 7) Driver/Left 3rd mounting location
Rear
(Fig. 8) Driver/Left rear mounting location
Fig. 9
Front
Factory 8mm threaded
insert in body panel
