The IRONCLAD Sensor Wire Stripping Process
1 2 3 4
5
6 7
8
9
10
Pull the clear wire out.
Pass the screwdriver
between the clear wire
and braid.
Split the GND braid to
either side.
Strip the clear wire.
The clear wire is the
sensing wire.
Attention!
1. Do not use any other method of stripping other than wire strippers. (do not use lighter to burn the
coating as it will harm the detection capability of the wire)
2. When stripping only use a proper tool, verify ALL wire strands stay intact.
