RC 40A ESC - Page 7

Ni-xx (NiMH / NiCad) battery pack: Set the cutoff voltage 50% (Low) / 65%
(Medium) / 75% (High) of the initial voltage (The voltage the ESC reads when the
battery pack is plugged in).
Li-xx (LiPo / Li-Ion) battery pack: Set the cutoff voltage per cell 2.8V (Low) / 3.0V
(Middle) / 3.2v (High). E.g. A 4s battery cutoff voltage will be 11.2V for Low, 12.0V as
Medium, and 12.8V as High.
5. Recover to factory default setting.
Factory default settings are as follows:
Settings
Default Parameter
Brake
Off
Type of Battery
LiPo / Li-Ion Battery
Low Voltage Protection
Medium / 3.0V / 65%
Timing
Automatic
Start-up
Smooth
Helicopter Mode
Off
Motor Rotation Direction
Normal
PWM Frequency
8kHZ
Protection Mode for Low Voltage
Reduce Power
5. Timing: Automatic / Low / High
Automatic: The ESC will detect the most suitable motor timing
automatically.
Low (7 – 22 degrees): Suitable for most inrunner motors.
High (22 – 30 degrees): Suitable for most outrunner motors.
*Note: Under most cases, the Automatic setting is suitable for all
motors. However, in order to increase efficiency, we recommend
using low timing for 2 poles (generally inrunner motors) and using
high timing for 6 and more poles (generally outrunner motors). We
